ProVIDEO High Definition

A truly versatile LED display solution

When you want to capture your audience’s attention, nothing matches an LED display’s ability to provide impactful, true-color images. AD SYSTEMS ProVIDEO indoor displays feature all the desirable LED qualities of brightness, dependability, long lifetime and low maintenance in an affordable package that meets your requirements for dynamic digital signage.

Customers today expect information-packed electronic displays with the high brightness, crisp image, and impactful content offered by ProVIDEO VIDEO screens. Available State-of-the-Art  SMD LED technology means exceptional performance for your indoor display. Renowned ProVIDEO image processing technologies ensure superb color uniformity and flicker-free video over the life of the display.

Endless content options

There are endless possibilities in the content that can be created and stored to be shown to customers with messages scheduling out to one year. This week you may want to display attention-grabbing text messages. Next week you may have a video sequence promoting a special offer. ProVIDEO High Definition LED Screens are the right solution for all your digital signage requirements.

ProVIDEO High Definition full color displays will ensure that you outperform your competitors with large-scale seamless images that really draw attention. ProVIDEO advertising is the best way to stand out from the crowd, whether you are communicating corporate information, visitor information, promotional, or advertising messages.

Whether you are equipping a retail outlet, museum, auditorium or corporate lobby, a ProVIDEO indoor LED display ensures that you have a high impact digital signage solution that combines the performance you need at a price you can afford.

High Performance

The ProVIDEO series gives you long term performance with low power consumption and maintenance requirements. ProVIDEO Video Displays are the most effective LED display solution with the lowest total cost of ownership over the lifetime of the display.



Other sizes are available as well as custom signs in other model lines. Inquire for more information.

Traditional “Picture Frame” Design


Highest Resolutions + Brightest LEDs = Best Graphics Quality

  • More Pixels for tightest 16mm in the industry: 15.85 mm
  • Blackest background and individual LED louvers make graphics pop
  • Ultra-High brightness versions of some pitches are available for locations with challenging sun exposures.

New ProFlex Cabinet Design


Available in two cabinet design options:

  • A sleek, 5” deep cabinet for displays upto 7”
  • 1.5” side borders on the face of the display
  • For larger sectional projects, an angled bezel border that makes the cabinet appear narrower

Resolution (Pitch) Comparison

Viewing
Distance
Close < 50’ distance Medium 50-150’ distance Long > 150’ distance
Resolution
(Pitch)
6mm 8mm 9mm 11mm 13mm 15mm 18mm 19mm 22mm
Brightness
(Nits)
8,500 6,500 12,500 10,000 9,500 12,500 12,000 10,000 9,000
Module Matrix
(Building Block)
40 x 40 32 x 32 32 x 32 16 x 32 24 x 24 20 x 20 8 x 8 16 x 16 8 x 8
Dimensions
(Per Module)
10.63" x 10.63" 10.63" x 10.63" 12.52” x 12.52" 7.4" x 14.8" 14.8" x 14.8" 14.8" x 14.8" 5.51” x 5.51" 14.8" x 14.8" 14.8" x 14.8"

Dependable by Design

Designed to be Efficient
  • Just the right brightness level with a high contrast surface
  • Efficient LEDs demand less energy
  • Louvers and ribbing in the module face maximize LED efficiency
Designed for Lasting Performance
  • Completely sealed components keeping Mother Nature Out
  • Signal redundancy ensuring your messages keep running
Tested For Reliability
  • Testing throughout development ensures a dependable final product
  • Tested to its limits in our state-of-the-art reliability lab

Simple Installation And Service

Easy Service

If your sign ever needs maintenance or service, technicians can access the components through the single-step module removal.



Quick Install

No matter how large the display, its features help make first-time fire ups successful:

  • Quick connections offer plug-and-play capability
  • External junction box for easy power connection
  • Mounting clips on the display back provide several easy ways to install the display
  • Front Access Maintenance simplifies service

2' 2.2" Height Displays
LED Model LED Color Brightness (Nits) Cabinet Dimensions Display Cost
AJ80x160RGB Red, Green, Blue 1,500 2' 2.2" x 3' 6.4" $12,000
AJ80x200RGB Red, Green, Blue 1,500 2' 2.2" x 4' 4.3" $12,500
AJ80x240RGB Red, Green, Blue 1,500 2' 2.2" x 5' 2.1" $12,700
AJ80x280RGB Red, Green, Blue 1,500 2' 2.2" x 5' 11.9" $13,600
AJ80x320RGB Red, Green, Blue 1,500 2' 2.2" x 6' 9.8" $14,900
AJ80x360RGB Red, Green, Blue 1,500 2' 2.2" x 7' 7.6" $16,300
AJ80x400RGB Red, Green, Blue 1,500 2' 2.2" x 8' 5.5" $21,300
AJ80x440RGB Red, Green, Blue 1,500 2' 2.2" x 9' 3.3" $22,500
AJ80x480RGB Red, Green, Blue 1,500 2' 2.2" x 10' 1.2" $23,700
AJ80x520RGB Red, Green, Blue 1,500 2' 2.2" x 10' 11" $25,900
AJ80x560RGB Red, Green, Blue 1,500 2' 2.2" x 11' 8.8" $27,200
3' Height Displays
LED Model LED Color Brightness (Nits) Cabinet Dimensions Display Cost
AJ120x80RGB Red, Green, Blue 1,500 3' 0.1" x 1' 10.7" $10,900
AJ120x120RGB Red, Green, Blue 1,500 3' 0.1" x 1' 10.7" $12,500
AJ120x160RGB Red, Green, Blue 1,500 3' 0.1" x 3' 6.4" $13,500
AJ120x200RGB 16:9 Red, Green, Blue 1,500 3' 0.1" x 4' 4.3" $14,100
AJ120x240RGB Red, Green, Blue 1,500 3' 0.1" x 5' 2.1" $15,500
AJ120x280RGB Red, Green, Blue 1,500 3' 0.1" x 5' 11.9" $16,900
AJ120x320RGB Red, Green, Blue 1,500 3' 0.1" x 6' 9.8" $18,400
AJ120x360RGB Red, Green, Blue 1,500 3' 0.1" x 7' 7.6" $20,300
AJ120x400RGB Red, Green, Blue 1,500 3' 0.1" x 8' 5.5" $27,800
AJ120x440RGB Red, Green, Blue 1,500 3' 0.1" x 9' 3.3" $29,100
AJ120x480RGB Red, Green, Blue 1,500 3' 0.1" x 10' 1.2" $30,400
AJ120x520RGB Red, Green, Blue 1,500 3' 0.1" x 10' 11" $31,800
AJ120x560RGB Red, Green, Blue 1,500 3' 0.1" x 11' 8.8" $33,300
3' 9.9" Height Displays
LED Model LED Color Brightness (Nits) Cabinet Dimensions Display Cost
AJ160x80RGB Red, Green, Blue 1,500 3' 9.9" x 1' 10.7" $12,500
AJ160x120RGB Red, Green, Blue 1,500 3' 9.9" x 2' 8.6" $13,100
AJ160x160RGB Red, Green, Blue 1,500 3' 9.9" x 3' 6.4" $15,100
AJ160x200RGB Red, Green, Blue 1,500 3' 9.9" x 4' 4.3" $16,700
AJ160x240RGB Red, Green, Blue 1,500 3' 9.9" x 5' 2.1" $18,500
AJ160x280RGB 16:9 Red, Green, Blue 1,500 3' 9.9" x 5' 11.9" $20,900
AJ160x320RGB Red, Green, Blue 1,500 3' 9.9" x 6' 9.8" $23,300
AJ160x360RGB Red, Green, Blue 1,500 3' 9.9" x 7' 7.6" $25,300
AJ160x400RGB Red, Green, Blue 1,500 3' 9.9" x 8' 5.5" $32,300
AJ160x440RGB Red, Green, Blue 1,500 3' 9.9" x 9' 3.3" $34,300
AJ160x480RGB Red, Green, Blue 1,500 3' 9.9" x 10' 1.2" $36,700
AJ160x520RGB Red, Green, Blue 1,500 3' 9.9" x 10' 11" $39,300
AJ160x560RGB Red, Green, Blue 1,500 3' 9.9" x 11' 8.8" $41,800
4' 7.8" Height Displays
LED Model LED Color Brightness (Nits) Cabinet Dimensions Display Cost
AJ200x80RGB Red, Green, Blue 1,500 4' 7.8" x 1' 10.7" $13,800
AJ200x120RGB Red, Green, Blue 1,500 4' 7.8" x 2' 8.6" $14,800
AJ200x160RGB Red, Green, Blue 1,500 4' 7.8" x 3' 6.4" $17,000
AJ200x200RGB Red, Green, Blue 1,500 4' 7.8" x 4' 4.3" $19,300
AJ200x240RGB Red, Green, Blue 1,500 4' 7.8" x 5' 2.1" $22,000
AJ200x280RGB Red, Green, Blue 1,500 4' 7.8" x 5' 11.9" $24,800
AJ200x320RGB Red, Green, Blue 1,500 4' 7.8" x 6' 9.8" $27,400
AJ200x360RGB 16:9 Red, Green, Blue 1,500 4' 7.8" x 7' 7.6" $29,700
AJ200x400RGB Red, Green, Blue 1,500 4' 7.8" x 8' 5.5" $38,000
AJ200x440RGB Red, Green, Blue 1,500 4' 7.8" x 9' 3.3" $41,200
5' 5.6" Height Displays
Model Number LED Color Brightness (Nits) Cabinet Size Display Cost
AJ240x80RGB Red, Green, Blue 1,500 5' 5.6" x 1' 10.7" $14,700
AJ240x120RGB Red, Green, Blue 1,500 5' 5.6" x 2' 8.6" $16,300
AJ240x160RGB Red, Green, Blue 1,500 5' 5.6" x 3' 6.4" $18,900
AJ240x200RGB Red, Green, Blue 1,500 5' 5.6" x 4' 4.3" $21,500
AJ240x240RGB Red, Green, Blue 1,500 5' 5.6" x 5' 2.1" $24,300
AJ240x280RGB Red, Green, Blue 1,500 5' 5.6" x 5' 11.9" $27,700
AJ240x320RGB Red, Green, Blue 1,500 5' 5.6" x 6' 9.8" $30,700
AJ240x360RGB Red, Green, Blue 1,500 5' 5.6" x 7' 7.6" $34,600

*Custom sizes are also available at no additional cost
